Manuál Hikoki CJ 110MV Vykružovačka

Manuál

3

English

5) Service

a) Have your power tool serviced by a qualied

repair person using only identical replacement

parts.

 Thiswillensurethatthe safetyofthepowertool is

maintained.

PRECAUTION

Keep children and inrm persons away.

When not in use, tools should be stored out of reach of

children and inrm persons.

JIG SAW SAFETY WARNINGS

1. Hold the power tool by insulated gripping surfaces,

when performing an operation where the cutting

accessory may contact hidden wiring or its own

cord.

Cutting accessory contacting a “live” wire may make

exposed metal parts of the power tool “live” and could

give the operator an electric shock.

2. Use clamps or another practical way to secure and

support the workpiece to a stable platform.

Holding the workpiece by hand or against your body

leaves it unstable and may lead to loss of control.

ADDITIONAL SAFETY WARNINGS

1. This jig saw employs a high-power motor. If the machine

is used continuously at low speed, an extra load is

applied to the motor which can result in motor seizure.

Always operate the power tool so that the blade is not

caught by the material during operation. Always adjust

the blade speed to enable smooth cutting.

2. Ensure that the power source to be utilized conforms

       

nameplate.

3. Ensure that the power switch is in the OFF position.

If the plug is connected to a receptacle while the power

switch is in the ON position, the power tool will start

operating immediately, which could cause a serious

accident.

4. When the work area is removed from the power source,



capacity. The extension cord should be kept as short as

practicable.

5. Dust produced in operation

The dust produced in normal operation may aect

the operator’s health. Either of following way is

recommended.

a) Wear a dust mask

b) Use external dust collection equipment

When using the external dust collection equipment,

connect the adapter with the hose from external dust

collection equipment.

6. During use, do not touch the metal portion of the tool.

7. Changing blades

  

from the receptacle when changing blades.

 

        

holder surely. (Fig. 1)

 

(Fig. 1)

8. At low speed (dial setting: 1 or 2) do not cut a wood with

a thickness of more than 10 mm or metal with a thickness

of more than 1 mm.

9. There is a possibility that chip cover is frosted when

cutting the metal.

10. Do not look in the light or see the source of light directly.

11. In order to prevent blade dislodging, damage or

excessive wear on the plunger, please make sure to

have surface of the base plate attached to the work piece

while sawing.

12. To ensure accurate cutting when using the guide

(Fig. 10), always set the orbital position to “0”.

13. When sawing a small circular arc, reduce the feeding

speed of the machine. If the machine is fed too fast, it

could cause the blade to break.

14. Circular cutting must be done with the blade

approximately vertical to the bottom surface of the base.

15. Angular cutting can not be done when adopting chip

cover or dust collector.

16. In order to prevent blade dislodging, damage or

excessive wear on the Plunger, please make sure to

have surface of the base plate attached to the work piece

while sawing.

17. RCD

The use of a residual current device with a rated residual

current of 30 mA or less at all times is recommended.

SYMBOLS

WARNING

The following show symbols used for the machine.

Be sure that you understand their meaning before

use.

CJ110MV / CJ110MVA : Jig Saw

To reduce the risk of injury, user must read

instruction manual.

Only for EU countries

Do not dispose of electric tools together with

household waste material!

In observance of European Directive 2012/19/

EU on waste electrical and electronic equipment

and its implementation in accordance with

national law, electric tools that have reached

the end of their life must be collected separately

and returned to an environmentally compatible

recycling facility.

V Rated voltage

Alternating current

P

Power input

n

0

No-load speed

kg

Weight (Only main body)

(According to EPTA-Procedure 01/2014)

Wood

Metal

Switching ON

Switching OFF

Disconnect mains plug from electrical outlet

Class II tool

0000Book_CJ110MV.indb 3 2019/03/05 14:40:07
