10

Ventilate room and seek medical attention in case of medical

symptoms. Gas can damage respiratory tract.

• Improper operation conditions may lead to battery electrolyte leak,

avoid contact with the substance. In case of accidental contact, ush

the electrolyte abundantly with water. In case of contact with eyes,

additionally seek medical attention. Leaked electrolyte may cause eye

irritation or burns.

• Do not disassemble the battery – there is a risk of short circuiting.

• Do not use power tool battery in rain.

• Always keep the battery away from sources of heat. Do not leave

the battery for a long time in high temperature (in direct sunlight,

in proximity of heaters and wherever the temperature exceeds 50°C).

Safety instructions for battery charger

• This equipment is not intended for use by persons with restricted

physical, sensory or mental capabilities (including children) or persons

who have no experience or are unfamiliar with the equipment, unless

the use is supervised or carried out in accordance with equipment

use instructions handed over by persons responsible for their safety.

• Pay attention to children so they don't play with the equipment.

• Do not expose the charger to humidity or water. Ingress of water

into the charger increases risk of electric shock. Use the charger only

in dry rooms.

• Disconnect the charger from power supply before starting any

maintenance or cleaning.

• Do not use the charger when placed on ammable surface (e.g.

paper, textiles) or in proximity of ammable substance. Greater

charger temperature when charging increases risk of re.

• Check condition of the charger, cable and plug before each

use. Do not use the charger if any damage is found. Do not try

to disassemble the charger. All repairs should be made at an

authorised service workshop. Improper charger assembly may cause

electric shock or re.

• Children and persons who are physically, emotionally or mentally

disabled and other persons, whose experience or knowledge is

insucient to use the charger while following all safety rules should

not use the charger without supervision of person responsible for

their safety. Otherwise there is a risk of improper use and injuries in

consequence.

• When the charger is not in use, it should be disconnected from the

mains network.

CAUTION! The design is assumed to be safe, protection measures and

additional safety systems are used, nevertheless there is always a

small risk of injuries at work.

Li-Ion batteries may leak, set on re or explode when heated to high

temperature or short-circuited. Do not store the batteries in a car in

hot and sunny days. Do not open the battery. Li-Ion batteries contain

electronic protection devices that, if damaged, may cause re or

explosion of the battery.

Explanation of used symbols

1 2 3 4

5 6

8

10 11

9

13 14

12

7

15

17 18

16

1. CAUTION! Use precaution measures.

2,3. Read instruction manual, observe warnings and safety conditions

therein!

4. Use personal protection equipment (protective goggles, earmu

protectors).

5. Remove the battery from the device before starting any

adjustments or cleaning related tasks.

6. Use protective gloves.

7. Keep the tool away from children.

8. Use protective clothes.

9. Use working shoes.

10. Protect the tool from moisture.

11. Do not put your hands or legs close to cutting parts.

12. The device is designed for outdoors use.

13. Disconnect the charger before repairs.

14. Protection class 2.

15. The charger is designed to operate indoors in dry environment.

16. Do not throw cells into re.

17. Maximum permissible cell temperature.

18. Recycling

CONSTRUCTION AND USE

Cordless hedge trimmer is a hand held device. Drive consists of a DC

commutator motor. Described hedge trimmer is designed for home

garden works, such as trimming hedges, bushes and shrubs. Any other

use, that is not allowed in this instruction manual, may cause damage of

the trimmer and constitute serious risk for the user. The hedge trimmer

is designed only for light duty use.

Use the tool only in accordance with its purpose.

DESCRIPTION OF DRAWING PAGES

Below enumeration refers to the device elements depicted on the

drawing pages of this manual.

1. Blade bar

2. Guard

3. Auxiliary handle

4. Switch lock button

5. Main handle lock button

6. Switch

7. Main handle

8. Battery locking button

9. Battery

10. Charger

11. LED diodes

12. Button for battery level indication

13. Battery level indicator (LED)

* Dierences may appear between the product and drawing

MEANING OF SYMBOLS

CAUTION

WARNING

ASSEMBLY / SETTINGS

INFORMATION

EQUIPMENT AND ACCESSORIES

1. Blade bar shield - 1 pce

PREPARATION FOR OPERATION

REMOVING AND INSERTING THE BATTERY

• Push the battery lock button (8) and slide out the battery (9) (g. A).

• Insert charged battery (9) into the handle holder, you should hear when

the battery lock button (8) snaps.

BATTERY CHARGING

The battery for the device is supplied partially charged. Charge the

battery in ambient temperature between 4°C and 40°C. New battery, or

one that has not been used for a long time, will reach full eciency after

approximately 3 to 5 charge/discharge cycles.

• Remove the battery (9) from the device (g. A).

• Connect the charger (10) to a mains socket (230 V AC).
