15

GB

Do not re-tighten or change the chain

when it is hot because it shrinks slightly

once it has cooled down. In case of non-

observance, this can lead to damages on

the guide rail or the engine because now

the chain is too taut on the blade.

Chain tension and chain lubrication have

a signicant impact on the service life of

the chain.

The chain is correctly tensioned if it does

not sag at the rail underside and can be

rotated completely around with the gloved

hand.

When the saw chain is tensioned with 9 N

(approx. 1 kg), the gap between the saw

chain and the guide rail may not be more

than 2 mm.

10 min

B

1. Ensure that the chain brake has

been released, that is, that the

chain brake lever (3) is pulled up

against the front grip (8).

2. Unscrew the fastening bolt (14).

3. To tighten the chain, turn the

chain adjustment ring (13) clock-

wise. To loosen the tension, turn

the chain adjustment ring anti-

clockwise.

4. Tighten up the fastening bolt (14)

again.

With a new saw chain, you must

readjust the chain tension after at

least 5 cutting operations.

Chain lubrication

The rail and chain must never be

without oil. If you operate the elec-

tric chainsaw with too little oil, the

cutting performance and the lifetime

of the saw chain is reduced, since

the chain becomes blunt faster. You

can identify a case of too little oil

where smoke development or dis-

coloration of the rail occurs.

As soon as the motor is speeded up, the oil

also ows faster to the chain bar (4).

Filling up with chain oil:

• Check the oil ll level (

C

21/22) and

regularly top up with oil. The oil tank

holds 270 ml oil.

• Use Parkside bio-oil; this product con-

tains additives that reduce wear and

tear and does not damage the pump

system. bio-oil is available from our

Service-Center.

• If you have no Grizzly bio-oil available,

use chain lubrication oil with low adhe-

sive additive content.

• Empty the oil tank before longer periods

(6-8 weeks) of non-use.

C

1. Unscrew the oil ll cap (2) and ll

up with chain oil.

2. Wipe off any spilled oil and

close the cap again.

Always switch off the device

and allow the motor to cool

before lling with chain oil.

There is a risk of re if oil

overows.

IB-270730-FKS_2200_E3-CB4-03112015-rev03-ts.indb 15 05.11.15 16:08
