Manuál Crivit IAN 307528 Trampolína

Manuál

9 GB/IE

Outdoor Trampoline

Introduction

We congratulate you on the purchase of your new product. You

have chosen a high quality product. Familiarise yourself with the

product before using it for the first time. In addition, please care-

fully refer to the operating instructions and the safety advice below. Only use

the product as instructed and only for the indicated field of application. Keep

these instructions in a safe place. If you pass the product on to anyone else,

please ensure that you also pass on all the documentation with it.

Failure to follow the safety instructions could lead to serious

injury.

Instructions for use

Before reading, fold out the illustration page and get to know all of the

functions of your product.

Intended use

This product is designed exclusively for private use.

The product is not suitable for therapeutic or commercial use. The product is

neither designed nor suitable to be installed in-ground.

Only for domestic use.

The trampoline is intended for outdoor use.

Items delivered / Description

of parts (fig. A)

1

1 x Jump mat

2

1 x Frame protection

3

1 x Enclosure net

4

5 x Angled rods

5

10 x Frame rods

6

5 x Enclosure poles lower

7

5 x Enclosure poles upper

8a

5 x Extension rods with holes

8b

5 x Extension rods

9

2 x Ladder rung

10

2 x Ladder hold

11

60 x Spring

12a

5 x Common section with hole

12b

5 x Common section

13

10 x Screw M6 x 70 mm

14

1 x Wrench

15

5 x Pole cap

16

15 x Self-tapping screw M4

17

4 x Screw M6 x 60 mm

18

4 x Screw M6 x 35 mm

19

8 x Feather washer

20

2 x Cuff

21

1 x Screwdriver

22

4 x Wing nut

23

10 x Spacer

24

9 x Nut

25

5 x Cap Nut

26

14 x Washer

27

6 x Rope

28

1 x Tool to tension the springs

Technical data

Maximum user load: 150 kg

Weight of Product: approx. 43 kg

Dimensions: assembled approx.: 305 x 258 cm

Safety notes

WARNING!

Warning! Max 150 kg.

Warning! The trampoline shall be assembled by an adult in accordance

with the assembly instructions and thereafter checked before the first use.

Warning! Adult assembly only, as there may be constituted a puncture

hazard during assembly.

Warning! Always close the net opening before jumping.

Warning! Jump without shoes.

Warning! Do not use the mat when it is wet.

Warning! Empty pockets and hands before jumping.

Warning! Always jump in the middle of the mat.

Warning! Do not eat while jumping.

Warning! Do not exit by a jump.

Warning! Limit the time of continuous usage (make regular stops).

Warning! Do not use in strong wind conditions and secure the trampoline.

Warning! Only one user. Collision hazard.

Warning! The net should be replaced every 3 years.

Warning! Please keep 2 m clear around the trampoline.

Warning! Adult supervision required.

Warning! No somersaults.

Warning! Read the instruction.

Warning! Ensure to drag the end of the strap as more as possible

during assembly (figure P).

Warning. Not suitable for children under 36 months.

Small parts. Choking hazard.

Suitable for children aged 6 and above, as it may be difficult

for younger children to cope with the physical and dynamic

characteristics of the trampoline mat, because they do not yet

have the required coordination skills.

CAUTION! RISK OF INJURY!

The product may only be used under adult supervision

Consult with your doctor before you begin exercising. Make sure that

you are in suitable health for the exercise.

Always remember to warm up before exercising and exercise in accord-

ance with your current abilities. Serious injury can occur if you exert your-

self too much and over exercise. Cease exercising immediately if you

experience discomfort, weakness, or fatigue and consult a doctor.

Keep the operating instructions with the exercise descriptions to hand at

all times.

Please note the maximum load bearing capacity of 150 kg. If this weight

limit is exceeded it can lead to damage to the product and compromise its

function.

Pregnant women should only use the product following consultation with

their doctor.

A free area of not less than 2 m shall remain around the exercising

area in the directions from which the equipment is accessed. No barrier

above the trampoline (e. g. branch).

Free standing equipment shall be installed on a stable base and properly

leveled.

Do not use the product in the vicinity of stairs or steps.

Never use the product in the vicinity of open fire or ovens.

This trampoline is not intended to be buried into the ground;

Place the trampoline on a level surface at least 2 m from any structure or

obstruction such as a fence, garage, house, overhanging branches, laun-

dry lines or electrical wires;
