- 5 -

CANDLE SELF-BALLASTED LAMP

ONLY WITH DOUBLE ENVELOPE

Ø 38mm - L108 - E14 - 7W

INCANDESCENT

TUBOLAR LAMP

Ø 25mm - L85 - E14 - 40W

CANDLE HALOGEN LAMP

Ø 35mm - E14 - 28W

Fig.15

ENGLISH

GB

GENERAL

Carefully read the following important information regarding

installation safety and maintenance. Keep this information

booklet accessible for further consultations. The appliance

has been designed for use in the ducting version (air exhaust

to the outside - Fig.1B), filtering version (air circulation on the

inside - Fig.1A) or with external motor (Fig.1C).

SAFETY PRECAUTION

1. Take care when the cooker hood is operating simultaneously

with an open fireplace or burner that depend on the air in the

environment and are supplied by other than electrical energy,

as the cooker hood removes the air from the environment

which a burner or fireplace need for combustion. The negative

pressure in the environment must not exceed 4Pa (4x10-5 bar).

Provide adequate ventilation in the environment for a safe

operation of the cooker hood. Follow the local laws applicable

for external air evacuation.

Before connecting the model to the electricity network:

- Control the data plate (positioned inside the appliance)

to ascertain that the voltage and power correspond to the

network and the socket is suitable. If in doubt ask a qualified

electrician.

- If the power supply cable is damaged, it must be replaced with

another cable or a special assembly, which may be obtained

direct from the manufacturer or from the Technical Assistance

Centre.

- This device must be connected to the supply network through

either a plug fused 3A or hardwired to a 2 fase spur protected

by 3A fuse.

2. Warning!

In certain circumstances electrical appliances may be a

danger hazard.

A) Do not check the status of the filters while the cooker

hood is operating.

B) Do not touch bulbs or adjacent areas, during or straight

after prolonged use of the lighting installation.

C) Flambè cooking is prohibited underneath the cooker

hood.

D) Avoid free flame, as it is damaging for the filters and a

fire hazard.

E) Constantly check food frying to avoid that the over-

heated oil may become a fire hazard.

F) Disconnect the electrical plug prior to any maintenance.

G) This appliance is not intended for use by young children

or infirm persons without supervision.

H) Young children should be supervised to ensure they do

not play with the appliance.

I) There shall be adequate ventilation of the room when

the rangehood is used at the same time as appliances

burning gas or other fuels.

L) There is a risk of fire if cleaning is not carried out in

accordance with the instructions.

This appliance conforms to the European Directive EC/2002/96,

Waste Electrical and Electronic Equipment (WEEE). By making

sure that this appliance is disposed of in a suitable manner, the

user is helping to prevent potential damage to the environ-

ment or to public health.

The symbol on the product or on the accompanying

paperwork indicates that the appliance should not be

treated as domestic waste, but should be delivered to

a suitable electric and electronic appliance recycling collection

point. Follow local guidelines when disposing of waste. For

more information on the treatment, re-use and recycling of

this product, please contact your local authority, domestic

waste collection service or the shop where the appliance was

purchased.

INSTALLATION INSTRUCTIONS



by specialised personnel.

-

lation.



Note! Verify the data label placed inside the appliance:

- If the symbol

appears on the plate, it means that no earth

connection must be made on the appliance, therefore follow

the instructions concerning insulation class II.

- If the symbol

DOES NOT appear on the plate, follow the

instructions concerning insulation class I.

Insulation class II

- The appliance has been manufactured as a class II, therefore

no earth cable is necessary.

The plug must be easily accessible after the installation of the

appliance. If the appliance is equipped with power cord with-

out plug, a suitably dimensioned omnipolar switch with 3 mm

minimum opening between contacts must be fitted between

the appliance and the electricity supply in compliance with the

load and current regulations.

- The connection to the mains is carried out as follows:

BROWN = L line

BLUE = N neutral.

Insulation class I

This is a class I, appliance and must therefore be connected to
