Daily Reference Guide

6

ATTENTION: Always unplug the appliance when cleaning it and when

performing maintenance work.Do not use ammable liquids to clean the

machine.

CLEANING THE DISHWASHER

Any marks on the inside of the appliance may be removed

using a cloth dampened with water and a little vinegar.

The external surfaces of the machine and the control pan-

el can be cleaned using a non-abrasive cloth which has

been dampened with water. Do not use solvents or abra-

sive products.

PREVENTING UNPLEASANT ODOURS

Always keep the door of the appliance ajar in order to avoid moisture from

forming and being trapped inside the machine. Clean the seals around the

door and detergent dispensers regularly using a damp sponge. This will

avoid food becoming trapped in the seals, which is the main cause behind

the formation of unpleasant odours.

CHEKING THE WATER SUPPLY HOSE

Check the inlet hose regularly for brittleness and cracks. If damaged, re-

place it by a new hose available through our After-Sales Service or your

specialist dealer. Depending on the hose type:

If the inlet hose has a transparent coating, periodically check if the colour

intensies locally. If yes, the hose may have a leak and should be replaced.

For water stop hoses: check the small safety valve inspection window (see

arrow). If it is red, the water stop function was triggered, and the hose must

be replaced by a new one. For unscrewing this hose, press the release but-

ton while unscrewing the hose.

CLEANING THE WATER INLET HOSE

If the water hoses are new or have not been used for an extended period of

time, let the water run to make sure it is clear and free of impurities before

performing the necessary connections. If this precaution is not taken, the

water inlet could become blocked and damage the dishwasher.

CLEANING THE FILTER ASSEMBLY

Regularly clean the lter assembly so that the lters do not clog and that

the waste water ows away correctly.

Using the dishwasher with clogged lters or foreign objects inside the l-

tration system or spray arms may cause unit malfunction resulting in loss of

performance, noisy work or higher resources usage.

The lter assembly consists of three lters which remove food residues

from the washing water and then recirculate the water.

The dishwasher must not be used without lters or if the lter is loose.

At least once per month or after every 30 cycles, check the lter assembly

and if necessary clean it thoroughly under running water, using a non-me-

tallic brush and following the instructions below:

1. Turn the cylindrical lter A in an anti-clockwise direction and pull it out

(Fig 1). It is important when reinstalling the lter that the two trian-

gles shown on the zoom meet.

2. Remove the cup lter B by exerting a slight pressure on the side aps

(Fig 2).

3. Slide out the stainless-steel plate lter C (Fig 3).

4. In case you nd foreign objects (such as broken glass, porcelain, bones,

fruit seeds etc.) please remove them carefully.

5. Inspect the trap and remove any food residues. NEVER REMOVE the

wash-cycle pump protection (shown by an arrow) (Fig 4).

CARE AND MAINTENANCE

2

1

4

3

A

A

B

C

After cleaning the lters, replace the lter assembly and x it in position cor-

rectly; this is essential for maintaining the ecient operation of the dishwasher.

CLEANING THE SPRAY ARMS

On occasions, food residue may

become encrusted onto the

spray arms and block the holes

used to spray the water. It is

therefore recommended that

you check the arms from time

to time and clean them with

asmall non-metallic brush.

To remove the upper spray you

must remove it together with

the manifold.

The Top Rack has a xed wash

tube with all the wash nozzles

facing upward. To clean it you can slide the rack out and with a tweezer

remove items that may be lodged in the nozzles.

The lower spray arm may be removed by

pulling it upwards and rotating it an-

ti-clockwise. Mounting back the spray

arm is by pulling it down and rotating it

clockwise.

The ceiling spray arm may be removed

by pressing it up and then rotating it

anti-clockwise. Mounting back the spray

arm is by pulling it upwards and rotating

it clockwise.
