WT 8700 RADIO CONTROLLED WALL CLOCK - Instruction manual

Environmental reception effects

The clock obtains the accurate time with wireless technology. Same as all wireless devices, the reception is maybe affected by the following circumstances:

• long transmitting distance

• nearby mountains and valleys

• near freeway, railway, airports, high voltage cable etc.

• near construction site

• among tall buildings

• inside concrete buildings

• near electrical appliances (computers, TV’s, etc) and metallic structures

• inside moving vehicles

Place the clock at a location with optimal signal, i.e. close to a window and away from metal surfaces or electrical appliances.

Precautions

• This main unit is intended to be used only indoors.

• Do not subject the unit to excessive force or shock.

• Do not expose the unit to extreme temperatures, direct sunlight, dust or humidity.

• Do not immerse in water.

• Avoid contact with any corrosive materials.

• Do not dispose this unit in a fire as it may explode.

• Do not open the inner back case or tamper with any components of this unit.

Batteries safety warnings

• Use only alkaline batteries, not rechargeable batteries.

• Install batteries correctly by matching the polarities (+/-).

• Always replace a complete set of batteries.

• Never mix used and new batteries.

• Remove exhausted batteries immediately.

• Remove batteries when not in use.

• Do not recharge and do not dispose of batteries in fire as the batteries may explode.

• Ensure batteries are stored away from metal objects as contact may cause a short circuit.

• Avoid exposing batteries to extreme temperature or humidity or direct sunlight.

• Keep all batteries out of reach from children. They are a choking hazard.

Use the product only for its intended purpose!

Start the clock

Insert 1 x Mignon AA LR06 battery into the battery compartment and make sure the battery polarity (+/-) is as indicated. The second hand is adjusting to 12 o’clock position and the clock

enters into signal reception mode.

Signal reception mode

a. Automatic signal reception: The automatic signal reception starts by inserting the battery. The second hand is adjusting to 12 o’clock position and the clock enters into signal

reception mode. If the signal is successfully received, the hands adjust automatically to the correct radio controlled time. This procedure takes approximately 2 to 10 minutes. If the

signal reception is failed, all the hands stop at 12 o’clock position. Then, the clock enters hourly again into signal reception mode. After the next successful signal reception, the

hands adjust automatically to the correct radio controlled time.

b. Manual signal reception: Press the REC button to start the manual signal reception at a freely selected time.

Manual time setup

(if no DCF-77 signal can be received)

Press and hold the TIME SET button for more than 3 seconds. The minute and hour hands start running forward. Hold the TIME SET button pressed until the desired time is set. If you

press the TIME SET button briefly, the minute hand moves forward each time by one minute. If the TIME SET button is not pressed for longer than 6 seconds, the setting is considered

complete.

Every night at 1:00 am the clock enters automatically into signal reception mode. If the signal is successfully received, the hands adjust automatically to the correct radio controlled time. If

the signal reception is failed, the clock enters hourly again into signal reception mode (up to max. 5:00 am). During this procedure the previously set time continues running without

interruption.

Notes:

• To save energy, the second hand stops between 0:00 and 6:00 o’clock.

• Replace the battery after one year, to guarantee the correct function of the clock.

• When the clock is not used for a long period of time, remove the battery.

• Maintenance and repairs must be performed only by an expert or a specialist workshop. If you have any questions that are not answered in this manual, please contact our Technical

Advisory Service or another specialist.

Consideration of duty according to the battery law

Old batteries do not belong to domestic waste because they could cause damages of health and environment. End-users are committed by law to bring back needed batteries to distributors and other collecting

points!

Consideration of duty according to the law of electrical devices

This symbol means that you must dispose of electrical devices separated from the General household waste when it reaches the end of its useful life. Take your unit to your local waste collection point or recycling

centre. This applies to all countries of the European Union, and to other European countries with a separate waste collection system.
