Assembly
WARNING: Read and understand the safety
chapter before you assemble the product.
To install the upper blower tube
1. Align the slot on the upper blower tube (A) with the
tab in the blower outlet (B). (Fig. 21)
2. Push the upper blower tube fully onto the blower
outlet.
3. Turn the upper blower tube until the hole in the tube
is aligned with the threads in the nut in the blower
outlet. (Fig. 22)
4. Install the screw (C). (Fig. 23)
5. Turn the screw clockwise with a screwdriver to
attach the tube.
To install the lower blower tube
1. Align the slots on the lower blower tube (A) with the
tabs on the upper blower tube (B). (Fig. 24)
2. Push the lower blower tube fully onto the upper
blower tube.
3. Turn the lower blower tube fully until the tab is
engaged at the end of the slot. (Fig. 25)
To install the VX
™
blower tube
1. Align the slots on the VX
™
blower tube (A) with the
tabs on the upper blower tube (B). (Fig. 24)
2. Push the VX
™
blower tube fully onto the upper
blower tube.
3. Turn the VX
™
blower tube fully until the tab is
engaged at the end of the slot. (Fig. 25)
To install the upper vacuum tube
1. Insert the tip of a screwdriver into the latch area of
the vacuum inlet. (Fig. 26)
2. Gently tilt the handle of the screwdriver toward the
front of the product to release the latch.
3. Hold the vacuum inlet cover open until the upper
vacuum tube is in place. (Fig. 27)
4. Align the rib on the inside of the vacuum inlet with
the slots on the upper vacuum tube.
Note: Align the indicators at the vacuum inlet
opening and on the upper vacuum tube.
5. Push the upper vacuum tube fully into the vacuum
inlet.
6. Turn the upper vacuum tube fully clockwise until you
feel a click. (Fig. 28)
To install the lower vacuum tube
1. Align the slot on the lower vacuum tube with the tab
on the upper vacuum tube.
2. Push the lower vacuum tube fully onto the upper
vacuum tube until the tab is engaged at the end of
the slot. (Fig. 29)
3. Install the screw.
4. Turn the screw clockwise with a screwdriver to
attach the tube. (Fig. 30)
To install the collection bag tube
1. Align the slot on the collection bag tube (A) with the
tab in the blower outlet (B). (Fig. 31)
2. Push the collection bag tube fully onto the blower
outlet.
3. Turn the collection bag tube until the hole in the tube
is aligned with the threads in the nut in the blower
outlet. (Fig. 32)
4. Install the screw (C).
5. Turn the screw clockwise with a screwdriver to
attach the tube. (Fig. 33)
Operation
WARNING: Read and understand the safety
chapter before you operate the product.
Fuel
To use fuel
CAUTION: This product has a two-cycle
engine. Use a mixture of gasoline and two-
cycle engine oil. Make sure to use the
correct quantity of oil in the mixture.
Incorrect ratio of gasoline and oil can cause
damage to the engine.
Gasoline
CAUTION: Do not use gasoline with an
octane number less than 90 RON (87 AKI).
This can cause damage to the product.
CAUTION: Do not use gasoline with more
than 10% ethanol concentration (E10). This
can cause damage to the product.
10 728 - 008 - 10.06.2019
