ENQuick Guide

1

CONTROL PANEL

PROGRAMS TABLE

Program

Programs description

Drying

phase

Auto

Door

Available

options

*)

Duration

of wash

program

(h:min)

**)

Water

con-

sumption

(litres/cycle)

Energy

con-

sumption

(kWh/cycle)

1.

Eco 50°- Program is suitable to clean normally soiled tableware, that for this

use, it is the most ecient programme in terms of its combined energy and

water consumption, and that it is used to assess compliance with the EU

Ecodesign legislation.

3:40 8.7 0.67

2.

Auto Intensive 65°- Automatic program for heavily soiled dishes and pans

(not to be used for delicate items).

2:00 - 3:10 14.0 - 17.0 1.50 - 1.85

3.

Auto Mixed 55° - Automatic program for normally soiled pans and dishes.

1:20 - 3:00 7.0 - 14.0 0.70 - 1.10

4.

Glass 45° - Program for delicate items, which are more sensitive to high tem-

peratures, for example glasses and cups.

1:40 12.0 1.20

5.

Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes with no

dried food residues. Without drying.

-

0:30 9.0 0.50

6.

Extra Hygiene 65° - Normally or heavily soiled crockery, with additional antibac-

terial wash. Can be used to perform maintenance of the dishwasher.

-

1:50 12.0 1.30

7.

Extra 50° - Program that allows to wash very big items loaded in the lower

rack. Please apply detergent directly to tub instead of detergent dispenser.

Upper rack should be removed with this cycle.

-

-

1:30 11.0 1.20

8.

Pre-Wash - Use to refresh crockery planned to be washed later. No detergent

to be used with this program.

- -

0:10 4.5 0.01

9.

Push&GO 50° - Everyday wash and dry cycle that ensures great cleaning per-

formance in a short time without the need to pre-treat dishes.

1:25 11.5 1.10

1. On-O / Reset button with indicator light

2. Program selection button with indicator

light

3. Half Load button with indicator light /

Tablet (Tab)

4. Eco program indicator light

5. Display

6. Program number and remaining time

indicator

4

1

32

965 7 8 1210 11 13

7. Tablet (Tab) indicator light

8. Closed water tap indicator

light

9. Rinse Aid rell indicator light

10. Salt rell indicator light

11. Push&GO button with

indicator light

12. Delay button with indicator light

13. Start/Pause button with indicator light / Drain out

THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive a more complete assistance, please

register your appliance on: www.indesit.com/register

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

A

C

D

FIRST TIME USE

More information in the Daily Reference Guide on website
