Quick GuideEN

2

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.indesit.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-

sales Service, please state the codes provided on your product‘s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model

identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

:

TROUBLESHOOTING

Please scan the QR code on your product in order to have more detailed information.

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher

does not ll the

water.

All LEDs are blink-

ing rapidly

No water in the water supply or the tap is

closed.

Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher

and reboot.

The sieve in the water inlet hose is clogged; it

is necessary to clean it.

After having carried out the verication and cleaning, turn o and turn on the

dishwasher and restart a new program.

Dishwasher

nishes the cycle

prematurely.

Drain hose positioned too low or siphoning

into home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check for

siphoning into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

UPPER RACK

(loading example for the upper rack)

Load delicate and light dishes: glass-

es, cups, saucers, low salad bowls.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

LOWER RACK

(loading example for the upper rack)

For pots, lids, plates, salad bowls, cutlery etc. Large

plates and lids should ideally be placed at the

sides to avoid interferences with the spray arm.

CUTLERY BASKET

It is tted with top grids

for improved cutlery ar-

rangement. It must only

be positioned at the

front of the lower rack.

Knives and other

utensils with sharp

edges must be placed

in the cutlery basket

with the points facing downwards or they

must be positioned horizontally in the tip-

up compartments on the upper rack.

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

A

A

B

C

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)

please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may be

removed by pulling it up-

wards.

DELAY - It is possible to delay the start time of the program by 2, 4 or

8 hours:

The DELAY function cannot be set once a wash cycle has been started.

PUSH&GO button is an easily distinguishable button that allows you

direct access to the Push&GO program, a wash and dry cycle that en-

sures great cleaning performance in a short time. You don’t have to worry

which program to choose, Push&GO cycle will do the work for you.

To select Push&GO program, switch on appliance, press only Push&GO

button for 3 seconds.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program

(see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

HALF LOAD - If there are not many dishes to be washed, a half load-

ing may be used in order to save water, electricity and detergent.

Remember to halve the amount of detergent.

Please scan the QR code on your product in order to have more detailed information.

AUTO DOOR is a convection drying system which automatically

opens the door during/after drying phase to ensure exceptional dry-

ing performance every day. Door opens at the temperature that is

safe to your kitchen furniture.
