Manuál Hoover HGH64SF X Varná deska

Manuál

07 GB

2.3. ADAPTING THE HOB TO DIFFERENT

TYPES OF GAS

To adapt the Hob for use with different types of gas, carry out the

following instructions:

•remove the grids and burners

•insert on hexagonal spanner (7 mm) into the burner support (Figure 7)

•Unscrew the injector and replace it with one suitable for the gas to be

used (see gas type table)

1)As illustrated, assemble parts in sequence:

A: 1/2 Male Adaptor Cylindirical

B: 1/2 Seal

C: 1/2 Female Gas Adaptor Conical-Cylindirical or

Cylindirical-Cylindirical

2)Tighten the joints with the spanner, remembering to twist the

pipes into position.

3)Attach fitting C to mains gas supply using rigid copper pipe or

flexible steel pipe.

IMPORTANT: carry out a final check for leaks on the pipe

connections using a soapy solution. NEVER USE A FLAME. Also,

make sure that the flexible pipe cannot come into contact with a

moving part of the cabinet (eg.adrawer) and that it is not situated

where it could be damaged.

Warning: If gas can be smelt in the vicinity of this appliance turn off the

gas supply to the appliance and call the engineer directly. Do not

search for a leak with a naked flame.

2.4. REGULATING THE MINIMUM FLAME

After lighting the burners, turn the control knob to the minimum setting

and then remove the knob (this can easily be removed by applying

gentle pressure).

Using a small «Terminal» type screwdriver the regulating screw can

be adjusted as in Figure 9. Turning the screw clockwise reduces the

gas flow, whilst turning it anticlockwise increases the flow – Use this

adjustment to obtain a flame of approximately 3 to 4 mm in length and

then replace the control knob.

When the gas supply available is LPG - the screw to set the idle flame

must be turned (clockwise) to the end stop.

When you have carried out the new gas regulation, replace the old gas

rating plate on your appliance with one (supplied with hob) suitable for

the type of gas for which it has been regulated.

3. USE OF HOB - USER INSTRUCTIONS

This appliance must only be used for the purpose for which it is

intended, domestic cooking, and any other use will be considered

improper and could therefore be dangerous. The Manufacturer will

not be responsible for any damage or loss resulting from improper

use.

3.1. USING THE GAS BURNER

To ignite the burners, place a lighted taper close to the burner, press in

and turn the control knob anti-clockwise.

If the burners have not been used for a couple of days, wait for a few

seconds before lighting the burner, this will allow any air present in the

pipes to escape.

For appliances fitted with electronic ignition carry out the following:

• push in and turn the knob anticlockwise to the ignition symbol.

• ignite the burner by pressing the sparker button.

For hobs fitted with automatic ignition simply push in and turn the knob

to the ignition symbol.

The ignition system will continue to generate sparks as long as the

control knob is being pressed.

If the burner has not ignited within 5 seconds, turn the knob to the 0

position and repeat the operation.

For models fitted with a safety tap (which cuts-off the flow of gas if the

flame is accidentally extinguished) the burners are ignited and

described above, but care must be taken.

Prior to switching on the gas hob ensure that the burners and burner

caps are correctly placed within their position.

GENERAL ADVISE

For best results, use cooking vessels with a flat surface. The size of

the surface should match the gas burner side as follows. Table A.

For smaller containers the gas burner should be regulated so that the

flame does not overlap the base of the pan. Vessels with a concave or

convex base should not be used.

WARNING: If a flame is accidentally extinguished, turn the knob

to the off position and do not attempt to re-ignite if for at least 1

minute.

If over the years the gas taps become stiff to turn it is necessary to

lubricate them.

Such operation must be carried out only by qualified Service

Engineers.

Table A

3.2 USE OF GRIDDLE

Working

burner

G20

G25

G30

G31

GZ 350

G20 20mbar G30 28-30mbar

G31 37 mbar Gz350 13 mbar

G20 25mbar

G30 36mbar

G25 25mbar

G30 36mbar

ø gas jet

1/100 mm

ø

U100 mm

gas jet ø

1/100 mm

gas jet

Qn

kW

Qmin

W

I/h

G20

I/h

GZ350

g/h

G30

g/h

G31

Qn kW

Qmin

W

I/h

G20

g/h

G30

Qn

kW

Qmin

W

It

025

g/h

G31

little

large

medium

maxi

double ring

76

101

118

144

141

50

66

80

94

96

104

132

160

190

191

1

1,75

2,5

3,5

3,5

230

360

530

700

1750

95

167

238

333

333

132

232

331

463

460

73

127

182

254

254

71

125

179

250

250

1,2

2

2,8

4

4

260

410

620

830

1900

114

190

267

381

381

87

145

204

291

291

0,9

1,6

2,25

3,2

3,2

230

360

530

700

1750

100

177

255

354

354

64

114

161

229

229

Table of gas consumption

1 W 0,860 Kcal/h

Hob type

Burner type

ø pan/pot (cm)

A;B;C;D;E;H;I.

R/H front burner

12÷18

A;B;C;D;E;H;I.

L/H front burne

10÷18

A;B;D;E;H.I.

R/H rear burner

18÷24

A;B;C;D;

L/H rear burner

24÷26

E:H;I.

L/H rear burner

18÷24

E

Central burner

24÷28

H

Central radiant plate CX

Do not overhang the

radiant plate

Resting position

When not in use the gdiddle must be placed as shown in below.
