ELICA CONNECT

The hood features a Wi-Fi function for remote connection

via the Elica Connect App. Minimum system requirements:

• 2.4GHz Wi-Fi b/g/n wireless router • Android or iOs

Smartphone. Via the stores, check that the app is

compatible with the operating system your Smartphone is

running.

Note: The ELICA manufacturer declares that this model of

household appliance with WiFi module radio equipment

complies with Directive 2014/53/EU.

The radio equipment operates within the 2.4GHz ISM

frequency band, the maximum radio frequency power

transmitted does not exceed 20 dBm (e.i.r.p.).

Warnings:

• Data protection: The data that the connected device

detects is collected to allow for all the services of the

connected appliance to be used. Further information on

how the collected data is processed and on the privacy

policy is available at www.elica.com.

• Availability in different countries: The Elica Connect

service is available in specific countries. For further

information, see the dedicated section at

www.elica.com or check for availability from your

Smartphone store by searching for the Elica Connect App.

• Future changes: Elica reserves the right to make any

changes deemed useful to improve the Elica Connect

service. As a result, the descriptions contained in this

manual are not binding and should be treated as purely

indicative.

OPERATION

CONTROL PANEL

THINGS TO KNOW BEFORE STARTING

This product requires some preliminary operations before

being used:

● NECESSARY OPERATION:

Radio Control pairing.

This product is designed to work with the Elica Radio

Control only. In order to be able to use this product, the

Radio Control must be paired.

Depending on the product purchased, you will find one of

the two Radio Controls shown in the figure:

Radio Control 1:

Radio Control 2:

The pairing instructions are given in the manual supplied

with the Radio Control.

When the Radio Control has been paired, both LEDs L1

and L2 on the hood will flash White.

Attention!: the main functions are indicated in the Radio

Control manual; the manual also contains other indications

of use and other functions with an explanation of how to

activate them using the Radio Control. In cases where no

reference is made to a specific Radio Control, the

indications are valid for both.

Note: The two Radio Controls are interchangeable, so it is

always possible to purchase the one not included with the

product from the store at www.elica.com.

● OPTIONAL OPERATION:

Hob selection.

The product is designed to adapt its performance in the

best way possible according to the hob on which it works.

By Default, the product is set to work with GAS hobs.

To change this setting, after pairing the Radio Control, see

the chapter “Hob settings”.

● AUTOMATIC OPERATION:

VOC sensor calibration

If the optional hob selection operation is NOT performed,

the VOC sensor calibration starts automatically 2min.

after the product has been connected to the mains.

Calibration lasts 5 min. LED L1 flashes Green and

switches off at the end of the calibration procedure.

Please note! During calibration, the motor is switched

on at speed 1. For more details on the VOC sensor, refer

to the chapters dedicated to this function below.

USING THE CONTROLS

● Suction speed

This product is equipped with 5 suction speeds including 2

timed booster speeds:

Booster 1 (speed 4) timed 15 min.

Booster 2 (speed 5) timed 5 min.

After the minutes indicated above, the suction speed will go

back to speed 2 automatically.

11
