USER'S MANUAL

R

BLENDER BK100N

3

1

B

1. Cap + measuring unit

with the volume of 30ml

2. Cover

3. Jug with the volume of 1.5l

4. Holder

5. Body

6. Control switch

CUTTING UNIT

A. Knife

B. Seal

C. Base

- power: 400W

- supply voltage: 230V ~ 50Hz

- allowable time of continuous

work: 60 seconds

- interval before restarting

work: 2 minutes

Before the first usage, one shall wash all the parts of the blender which come in contact with food, that is: a

cap (1), a cover (2), a jug (3) and a cutting unit (photo 2).

- in order to disassemble the cover (2) one shall turn it clockwise and slide out. The cap (1) which is located

in the cover shall be disassembled in an analogical way.

- in order to disassemble the jug (3) one shall turn it clockwise and slide out while holding

the holder (4)

- for the purposes of washing, the cutting unit which is located on the bottom of the jug (3) shall also be

disassembled. It shall be turned anti-clockwise and slid out (photograph 4). It is not allowed to immerse the

cutting unit in total in water. Before the reassembly, all the elements have to be dried completely.

SERVICING

- make sure that the appliance is disconnected from power network and the switch (6) is set in „0” position

- the body (5) has to be placed on a flat and stable surface

- assemble the jug (3) together with the cutting unit. The jug (3) has to be placed on the body (5) and turned

anti-clockwise (photograph 5)

The appliance is equipped in a device which protects it against starting it without the properly seated jug (3).

In case of problems with starting the blender, it is necessary to check whether the above mentioned element

is appropriately assembled.

- place food products in the jug (3). The maximum allowed level is marked on the jug (MAX).

In order to avoid splashing it is recommended not to exceed the volume of 1.2 l.

- place the cover (2) on the jug (3) and block it by means of turning it anti-clockwise

- put the cap (1) into the opening in the cover (2) and block it by means of turning it anti-clockwise

- connect the appliance to power

- depending on the products processed, select with a switch (6) low or high speed (item 1 or 2)

- in order to turn on impulse work, one shall turn and hold the switch (6) in „P” position.

After releasing the switch it automatically goes back to „0” position.

After completing work one shall set the switch (6) in „0” position, disconnect the appliance from network and

wait for the knife (A) to stop.

2

4

5

6

A

C

PHOTOGRAPH 1

PHOTOGRAPH 2

PHOTOGRAPH 3

GENERAL DESCRIPTION

TECHNICAL DATA

USING THE APPLIANCE

5
