56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER/BRUSH CUTTER — BCX450010
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
WARNING: Always wear eye protection, along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING: To prevent serious personal injury,
remove the battery pack from the machine before
servicing, cleaning, changing attachments or removing
material from the unit.
APPLICATIONS
The product may be used in rain.
You may use this product for the purposes listed below:
Trimming: used for removing grass and weeds up against
walls, fences, trees and borders.
Cutting: used for cutting the grass that is difficult to
reach using a normal mower.
NOTICE: The machine is to be used only for its prescribed
purposes. Any other use is deemed to be a case of
misuse.
ATTACHING/DETACHING THE BATTERY
Use only with EGO’s battery packs and chargers
listed in Fig.A2.
NOTICE*:
The battery packs of BA1400 and BA1400T
should not be used when the machine is equipped with
the brush cutter head.
Fully charge before rst use.
To Attach (Fig. E1)
Align the battery ribs with the mounting slots in the tool
battery port and slide the battery pack until it snaps into
position.
To Detach (Fig. E2)
Depress the battery-release button and the battery pack
will disengage from the latch.
WARNING: Always be aware of the location of your
feet, children, or pets when pressing the battery-release
button. Serious injury could result if the battery pack falls.
NEVER remove the battery pack at a high location.
MOUNTING THE DOUBLE-SHOULDER STRAP AND
HOLDING THE MACHINE
1. Put the double-shoulder strap on your body and
insert the two parts of the strap buckle into each
other until a click is heard (Fig. F1).
2. Align the hook of hip pad into eyelet of the shoulder
strap loop fixed on the shaft, and press the shaft
down softly (Fig. F2 & F3 & F4).
3. Hold the brush cutter with both hands on the right
side of your body (Fig.F5). The trimmer head should
be parallel to the ground so that it easily contacts
the material to be cut without the operator having to
bend over.
4. Releasing the string trimmer can be achieved in two
ways; Release the strap buckle (Fig. F6) or press the
hook of the strap and take it apart from the eyelet
fixed on the shaft (Fig. F2).
WARNING: When an emergency occurs, take it off
from your shoulder immediately, no matter what way the
strap is in. Releasing the strap buckle (Fig. F6) and both
hands taking off your shoulders at each side is a quick
release method
WARNING: You should not use the single-shoulder
strap and double-shoulder strap simultaneously.
STARTING/STOPPING THE MACHINE (Fig. G)
To Start
1. Move the lock-off lever up until it completely fits into
the groove, hold it in that position and then press the
trigger switch to start.
2. Different pressure on the trigger results in variable
rotating speed of the cutting unit. Adjust the speed to
suit the task at hand.
NOTICE: The motor starts only when the lock-off lever is
moved forward and the trigger switch is depressed at the
same time.
To Stop
Move the machine away from the cutting area and release
the trigger switch to stop it.
WARNING: Always remove the battery pack from the
machine during work breaks and after finishing work.
