Warning! Please note that the pump

plunger and pump cylinder become very

hot over longer periods of pumping due to the

friction between them. For this reason, you

should only grasp the floor pump on the pump

handle after pumping in order to avoid burns.

- Due to the risk of injury, a defective or dam-

aged floor pump may never be used.

Warning! Some bicycle valves do not

allow pressure display. For your own safety,

please check the air pressure with a calibrated

manometer (i.e. at a fuel station).

Initial use of the floor pump:

(B1 / B5)

(B1) Place the floor pump on a level and stable

surface.

(B2) There must be no kinks in the pump hose.

(B3) During pumping, please always position

yourself with both feet on the foot plate of the

floor pump to ensure it won’t fall over.

(B4) Operate the pump handle in a smooth and

even manner and not too quickly.

!

(B5) There is a red pointer in the middle of

the manometer. This red pointer can serve as an

optical mark for the desired pressure.

Turn the red pointer to the desired pressure dis-

play for this purpose.

Please note that the set mark only serves as orien-

tation and does not influence the air pressure!

Adapter: (C1)

The floor pump has been provided with a

pump head with a reversible valve adapter. As

delivered, the pump head has been set to use the

SCHRADER (large opening) adapter. To switch

to using the DUNLOP/PRESTA adapter (smaller

opening), flip the lever (A) upwards horizontally.

Do NOT pull the lever. Unscrew the valve adapter

from the pump head. Turn the valve adapter so

that the larger opening will be screwed into the

pump head (b).

Note: screw the valve adapter slowly onto

the pump head to prevent it from tilting during

screwing.

Adapter: (C1)

(1) E.g. balls

(2) E.g. air mattresses

(3) E.g. inflatable boats

(4) To inflate inner tubes with schrader valves

e.g. mountain bikes, trolleys and trailers.

(5) To inflate inner tubes with dunlop valves,

e.g. city/trekking bicycles

(6) For inflating inner tubes with a presta valve,

e.g. on racing bicycles and mountain bikes.

(7) Pump head (To lock in place, please fold

down the lever of the pump head.)

(Valves (4), (5), (6) not included)

Inflating tyres with a schrader valve: (C2)

First remove the dust protection cap (1). Insert the

pump head with the large opening into the valve

(2). To lock in place, please fold down the lever of

the pump head (3).

Inflating tyres with a dunlop valve: (C3)

First remove the dust protection cap (1). Insert the

pump head with the small opening into the valve

(2). To lock in place, please fold down the lever of

the pump head (3).

Inflating tyres with a presta valve: (C4)

First remove the dust protection cap (1). Detach

the valve nut (2a-2c). Insert the pump head with

the small opening into the valve (3). To lock in

place, please fold down the lever of the pump

head (4).

Inflating air mattresses, inflatable toys,

etc.: (C5)

First open the valve plug (1). Select the appropri-

ate plastic adapter and insert it into the large

opening of the pump head (2). To lock in place,

please fold down the lever of the pump head (3).

Now insert the plastic adapter into the object to

be inflated (4).

Inflating balls: (C6)

Insert the metal adapter in the large opening of

the pump head (1). To lock in place, please fold

down the lever of the pump head (2). Now insert

the metal adapter into the ball (3).

!

Cleaning & care instructions:

- clean with a damp cloth

- do not immerse in water

- regularly inspect the floor pump’s screw joints

for secure attachment before use

- the floor pump is maintenance-free.

- Store the floor pump in a cool, dry place pro-

tected from UV light.

Disposal:

Packaging is made of 100 % environmentally-

friendly materials that can be disposed of at

your local recycling point.

Please enquire with your community or munici-

pal administration regarding possibilities for the

disposal of the product.

Warranty:

Warranty of the MONZ Handelsgesellschaft Inter-

national mbH & Co. KG.

Dear customer, this device comes with a three-

year warranty, valid from the date of purchase. In

case of defects of this product, you will have legal

rights towards the seller of this product. These

legal rights shall not be limited by our warranty as

set out below.

Warranty terms:

The warranty term starts on the date of purchase.

Please keep the original receipt in a safe place.

This document is required as proof of purchase.

If within a period of three years following the

date of purchase, this product displays material

or manufacturing defects, we shall - at our discre-

tion - repair or replace the product free of charge.

This warranty assumes that within a period of

three years the defective device and the proof of

purchase (receipt) are submitted and that a brief

written description of the defect, including when it

occurred, is provided.

If the defect is covered by our warranty, you shall

receive a repaired or a new product. The repair

or exchange of the product does not commence a

new warranty term.

Distributor:

MONZ Handelsgesellschaft

International mbH & Co. KG

Schöndorfer Str. 60–62

54292 Trier / Germany

Service address:

MONZ SERVICE CENTER

c/o Teknihall Elektronik GmbH

Breitefeld 15, 64839 Münster / Germany

Hotline: 00800 / 68546854 (free of charge,

mobile networks may vary)

E-Mail: [email protected]

Dated: 07/2018

Ident-Nr.: PO30000381-26235
