10 | English
F 016 L81 438 | (27.9.16) Bosch Power Tools
– before changing the multi-tool at-
tachment
The extension pole may not be fitted
to the blower attachment.
Do not modify this product. Unau-
thorized modifications may impair
the safety of your product and may
result in increased noise and vibra-
tion.
After use, disconnect the machine
from the mains and check for damage.
Keep all nuts, bolts and screws tight
to be sure that the machine is in safe
working condition.
Examine the machine and replace
worn or damaged parts for safety.
Replace worn or damaged parts for
safety.
Ensure replacement parts fitted are
Bosch approved.
Store the machine in a secure, dry
place out of the reach of children.
Do not place other objects on top of
the machine.
Symbols
The following symbols are important for reading and under-
standing the operating instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the garden product in a better
and safer manner.
Intended Use
This multi-tool attachment can only be operated by the power
unit AMW 10.
The product is intended for blowing leaves, garden waste
such as grass, twigs and pine needles.
Technical Data
Noise/Vibration Information
The following information is applicable for the attachment op-
erated by the power unit:
Sound emission values determined according to
EN 50636-2-100.
Typically the A-weighted noise levels of the product are:
Sound pressure level 92 dB(A); sound power level
100dB(A). Uncertainty K=2dB.
Wear hearing protection!
Vibration total values (triax vector sum): Vibration emission
value a
h
= 3.5 m/s
2
, Uncertainty K= 0.6 m/s
2
.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical data” in combination with power
unit AMW 10 (3 600 HA3 0..) is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,
2006/42/EC, 2000/14/EC including their amendments and
complies with the following standards: EN 60335-1,
EN 50636-2-100, EN 50581.
2000/14/EC: Guaranteed sound power level 104 dB(A).
Conformity assessment procedure according to Annex V.
Equipment category: 34
Technical file (2006/42/EC, 2000/14/EC) at:
Bosch Lawn and Garden Ltd., PT-LG/ENS23,
Stowmarket, Suffolk IP14 1EY, England
Robert Bosch Power Tools GmbH
70538 Stuttgart, GERMANY
Stuttgart, 01.01.2017
Symbol Meaning
Wear protective gloves
Movement direction
Audible noise
Pole Leaf Blower Attachment AMW LB
Article number
3 600 HA3 F00
No-load speed
min
-1
8000
Air speed, max.
km/h 220
Volume flow rate, max.
m
3
/h 320
Weight according to
EPTA-Procedure 01:2014
kg 1.3
Serial number
see type plate on the gar-
den product
Please observe the article number on the type plate of your garden prod-
uct. The trade names of the individual garden products may vary.
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ECS
OBJ_BUCH-2223-003.book Page 10 Tuesday, September 27, 2016 8:35 AM
